Védő áramkör és egyensúlyozó 4 LiFePO4 cellához, áram akár 100A

Protection and charging module for 4 LiFePO cells with control of each cell separately. With this module, cells can be connected in series without the risk of damaging or destroying the cells. When charging, all cells are balanced according to their status and degree of charge.. Technical parameters :. - overcharge protection: 3.61 - 3.69 V. - resumption of charging at: 3.5 - 3.6 V. - protection activation and deactivation delay: 1.5 - 2.5 s. - protection against deep discharge: 2.27 - 2.43 V. - resumption of discharge at: 2.45 - 2.65 V. - discharge current: max 100 A, then the power supply is interrupted. - continuous discharge current: <80 A. - short-circuit protection: 100 - 600 microseconds. - charging current: max.60 A. - cell balancing during charging: 50 mA. The product is not a stand-alone unit, it requires professional installation.
