Vezeték nélküli modul NRF24L01 + 2.4GHz antennával

With the RF24L01 wireless module, two or more Arduino projects can be communicated wirelessly. For example, between one Arduino board, which measures the outdoor temperature and humidity, and the other, which ensures the display of measured data on the display.. Wireless communication between these units can then be realized simply by means of these electronic modules built on the nRF24L01 + chip. Just connect an Arduino or other control board to the module and you can start communicating.. To avoid the effects of interference, the nRF24L01 + modules use advanced wireless communication algorithms and are therefore suitable for industrial applications where interference occurs. Wireless modules have very low power consumption and advanced power saving mode, which allows long-term operation, for example, only from the battery.. Technical parameters:. - chip: NRF24L01. - 3.3V power supply (tolerance inputs 5V). - communication speed up to 2Mbps. - integrated antenna for communication at a distance of about 100m. - point-to-point or point-to-multipoint communication. - CRC error detection, frequency hopping. - SPI communication interface. - connection via 2 × 4 pin connector (pin spacing 2.54 mm). - built-in power supply and crystal. - very low current consumption and advanced low power mode. - dimensions 28 × 15 × 13mm. The product is not a self-functional unit, it requires professional assembly.
