LiFePO4 12,8V 200Ah SOLARFAM battery with Bluetooth heating

The Solarfam AST-320 LiFePO4 battery is designed primarily for caravans and solar systems with a nominal voltage of 12-24-36-48V. It includes an integrated battery management BMS for charge and discharge control and bluetooth monitoring (XiaoXiangElectric app available on GooglePlay and iOs). Can be arranged in parallel and serial, max 4 batteries. Ideal replacement for lead-acid batteries with multiply longer life (up to 5000cycles.)

Battery includes heating.
Serial and parallel shifting possible.


Technical parameters:
Model: AST-320
Nominal voltage: 12.8V
Capacity 320Ah
Energy: 4096Wh
Charging Voltage: 14.6V
Load shedding: 9.2V
Charging mode: CC/CV (1 phase constant current, 2 phase constant voltage)
Rated charging current: 100A
Peak charging current: 300A
Max. discharge current: 300A
Life: >3000cycles at 0.2C capacity drop (80% new battery condition), >5000cycles/0.5C
Self-discharge: 3%/month
Discharge capability up to 0.1C (10% of capacity)
Integrated charging automation (BMS-battery management system) - bluetooth 4.0
Charging temperature: 0° to 45°C
Heating function: -35° to 5°C
Discharge temperature: -20° to 60°C
Storage temperature: -5° to 35°C
IP protection: IP65
Thread on battery contact: M8
Dimensions (LxWxH): 353×198×250mm
Weight: 27.2kg
