Charger XTAR PB2S BAT1147

XTAR PB2S BAT1147 charger
Professional processor charger for Li-ion 18650/20700/21700/26650 cells with PowerBank function

- three-phase charging: TC / CC / CV
- two independent charging channels
- reactivation of deeply discharged cells and
- charging current of 0V cells: 2x2A / 2x1A / 1x2A | charging voltage: 4.2V
- efficient converter - 92% efficiency
- magnetic cover for the charging chamber
- powered by USB TYPE C QC 3.0 and PD 3.0 - (without power adapter)
- protection: thermal, short circuit, against battery reinsertion
- dimensions: 125 x 58 x 28mm

The small case hides a fully professional processor charger with a power bank function with a three-stage TC / CC / CV charging process. Charges 3.6 / 3.7 V Li-ion cells of any capacity in size 18650/20700/21700 / 26650. The intelligent built-in balancer controls the charging and discharging process. Thanks to it, the lifespan of the cells is significantly extended. The charger always starts by charging the most discharged cell. After reaching a similar level of charge, it will start charging both batteries simultaneously. The same happens in case of discharge. The charger starts discharging from the more charged cell, after equalizing the charge levels, it starts discharging both accumulators simultaneously (power bank function).

The Xtar PB2S charger kit includes a USB TYPE C cable. The kit does not include a power adapter. Any charger with a USB connector will suffice to power the charger, e.g. from a phone or computer with a free USB port. The recommended charging source is one that supports QC3.0 / PD3.0 to take full advantage of the charger. It is possible to use a charger with a lower power, but in this case the charging time will be longer.
