Battery LiFePO4 12,8V 200Ah SOLARFAM AST-100 with Bluetooth heating

The Solarfam AST-100 battery is designed primarily for caravans and solar systems with a nominal voltage of 12-24-36-48V. It includes an integrated battery management BMS for charge and discharge control and bluetooth monitoring (XiaoXiangElectric app available on GooglePlay and iOs). Can be arranged in parallel and serial, max 4 batteries. Ideal replacement for lead-acid batteries with multiply longer lifetime.

The battery includes a heater.
Serial and parallel shifting possible.

Technical parameters:

- Model: AST-100
- Nominal voltage: 12.8 V
- Capacity 100 Ah
- Energy: 1280 Wh
- Charging voltage: 14.4 V
- Load shedding: 9.2 V
- Charging mode: CC/CV (1 phase constant current, 2 phase constant voltage)
- Nominal charging current: 20 A
- Peak charging current: 100 A
- Max. discharge current: 100 A
- Discharge capability up to 0.1C (10% of capacity)
- Integrated charging automation (BMS-battery management system) - Bluetooth 4.0
- Charging temperature: 0° to 60°C
- Discharge temperature: -20° to 70°C
- Storage temperature: -5° to 35°C
- IP protection: IP65
- Thread on battery contact: M8
- Dimensions (LxWxH): 303×175×169 mm
- Weight: 11 kg
