Backup power GETI GEP301 sinus 300W Wall-mounted + battery 28Ah

The GETI emergency power supply system (EPS - Emergency Power Supply) is a device that provides a source of alternating voltage in the event of a power failure. You can use the Power Supply System (EPS) as a backup source for various pumps, automatic boilers, feeders, emergency lighting, camera systems and more. In normal mode, the connected device is powered directly from the network, and in the event of a failure, the emergency power system automatically switches to inverter mode. The connected device is then powered by the connected battery. If the power supply is not restored, the system (EPS) may switch off when the voltage of the connected battery drops to a value of around 10.2V ± 0.3V. This is to protect the battery from deep discharge and subsequent damage. The EPS is equipped with a clear colour display, a pure sine voltage converter based on a toroidal transformer and a fast 32-bit processor.

Warning: the contacts of the connected battery must be properly protected against: contact with persons, foreign bodies, contact with other parts of the system or short circuits.

Product description:

- inverter, UPS, AVR and charger in one device
- clear LED colour display
- high efficiency due to construction with toroidal transformer
- high charging current
- protection against overload, short circuit, overcharging and reverse polarity.



Technical parameters:

- type of backup batteries: AGM, GEL
- backup battery voltage: 12V DC
- rated capacity: 500VA
- rated power: 300W
- transformer: toroid
- input voltage: 230 V AC - 50Hz
- output voltage: 230V AC ± 3% - 50Hz / pure sine wave
- charging current: 5 A / 10 A optional
- charging voltage: 13.6V ± 0.3V
- low battery voltage limit: 11 V ± 0.3V
- battery low voltage protection point: 10.5V ± 0.3V
- transfer time: < 4 ms
- cooling system: Yes
- operating temperature: 0 ~ 40°C
- relative humidity: 10% ~ 90%
- storage temperature: -15°~ 45°C
- cable length to battery: 2 x 75 cm, M8
- dimension: 210x253x102 mm
- weight: 4 kg


Technical parameters:

- production technology: VRLA - valve regulated lead acid
- type: AGM
- voltage: 12 V
- capacity: 28 Ah
- dimensions: 166 x 175 x 125 mm
- large height (with terminals): 125 mm
- connection (terminals): flat connector for 5.5 mm screw
- weight: approx. 8.3 kg


Packaging: 1 pc GETI GEP301 backup power source + 28AH lead battery
Weight: 12,5 kg
